Note: The goggles are upgraded versions with the face sponge and AV IN function. The Headphone jack was changed to 3.5mm. The total weight reduction of 26g.
| Specification | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Brand name | Eachine | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Item No. | EV800 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Screen | Screen size: 5.0 inch Screen resolution: 800*480 (No blur after enlarge by the lens) Screen brightness: 600cd/m2 with special high brightness backlight LED for outdoor FPV View Angle: 140/120 degree(Horizontal/Vertical) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lens | 3x boost of the video to acquire intense feel-in-there video; 92% transparent rate no distort of light; | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Battery and recharge | Built-in 3.7V/2000mAh battery; Each battery circle offer around 3.5hr working time; 5-12V wide recharging voltage range, typical recharging voltage is 5V Accepts 5V power banks or 2S(7.4V)/3S(11.1V) battery as back-up power to have long working time | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Receiver | Build in 5.8G 40CH Raceband receive
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Body | Dimension: 180x145x82mm Weight: 349g with 3.5hr 2000mAh battery Belt: three-ways adjustable belt | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
Feature:
– With comfortable face sponge and AV IN function;
– Separable design, 5 inch screen can be used as small monitor on radio controller or with tripod;
– HD high brightness 5inch LCD specially tuned for FPV racing;
– Built-in super sensitiveness 5.8GHz 40ch receiver, especially with RaceBand;
– Come with advanced auto-searching function ad show you the working frequency on screen;
– Built-in 3.7V/2000mAh battery, each full charge revive around 3.5hours working time;
– Wide range re-charge voltage 5-12V, power banks or 2S/3S batteries can be used as back up power sour, to prolong the working time;
– Ergonomic design fit your faces;
– Super-wide visible angle up to 82 degree;
– 92% transparent lens adopted, no distort, no blur on the adage of screen;
– Light weight 375g with 3.5hr 2000mAh battery, RTF for any scale racing game.
– 5 inch 800*480px HD high brightness LCD
Package Included:
1 X EV800 FPV VR Goggles
1 X Antenna
1 X USB charger cable
1 X Battery charger cable
1 X AV IN cable
1 X User Manual
1 X Clean cloth
1 X Bag
,
,
,
,
,
,
,
